3GR螺杆泵
2013-9-14 10:10:07
3G三螺杆泵适用介质及性能范围:
3GR螺杆泵所输液体为各种不含固体颗粒,无腐蚀性油类及类似油的润滑性液体,所输液体粘度为1.2~100°E(3.0~760cst),高粘度 液体亦可通过加温降粘后输送. 流量范围0.2~590m3/h,最高工作压力100bar,最高温度150℃.
|
泵型号 |
流量 |
压力 (公斤) |
转速转/分 |
功率(KW) |
吸入高度(米) |
进口(mm) |
出口(mm) |
电机形式 | |||
|
立方/小时 |
升/分 |
轴功率 |
电机功率 | ||||||||
|
3G
3GC
3Gr
3GCr
3GCG
3GCL
3GCLS
|
25×4 |
2.0
1.6 |
33
26 |
10
25 |
2900 |
1.1
2.2 |
1.5
3 |
6 |
25 |
20 |
B3
|
|
0.8
0.6 |
13
10 |
10
25 |
1450 |
0.5
1.1 |
0.75
1.5 |
6.5 |
B3 | ||||
|
25×6 |
1.6
1.4 |
26
23 |
40
60 |
2900 |
3.4
5 |
4
5.5 |
6 |
25 |
20 |
B3 | |
|
0.6
0.4 |
10
6.6 |
40
60 |
1450 |
1.6
2.5 |
2.2
3 |
6.5 |
B3 | ||||
|
30×4 |
3.6
3.2 |
60
53 |
10
25 |
2900 |
1.9
3.8 |
2.2
4 |
5.5 |
32 |
25 |
B5 | |
|
1.6
1.2 |
26
20 |
10
25 |
1450 |
0.9
1.9 |
1.5
2.2 |
6 |
B5 | ||||
|
36×4 |
6.5
6 |
108
100 |
10
25 |
2900 |
3.2
6.2 |
4
7.5 |
5 |
50 |
40 |
B3 | |
|
2.8
2.4 |
46
40 |
10
25 |
1450 |
1.6
3.1 |
2.2
4 |
5.5 |
B3 | ||||
|
36× 6A |
6
5 |
100
83 |
40
60 |
2900 |
10
15.5 |
15
18.5 |
5 |
50 |
40 |
B3 | |
|
2.4
2 |
40
33 |
40
60 |
1450 |
4.8
7.7 |
5.5
11 |
5.5 |
B3 | ||||
|
42× 4A |
10.5
10 |
175
166 |
10
25 |
2900 |
4.9
9.5 |
5.5
15 |
4.5 |
65 |
40 |
B3 | |
|
4.8
4.2 |
80
70 |
10
25 |
1450 |
2.4
4.7 |
4
5.5 |
5 |
B3 | ||||
|
42× 6A |
10
9 |
166
150 |
40
60 |
2900 |
16
21.5 |
18.5
30 |
4.5 |
65 |
40 |
B3 | |
|
4.2
3.6 |
70
60 |
40
60 |
1450 |
7.5
10 |
11
15 |
5 |
B3 | ||||
|
50×2 |
17.5
16
18 |
291
266
300 |
6
10
4 |
2900 |
5.2
8.1
3.6 |
5.5
11
4 |
4.5 |
80 |
50 |
B3.B5.V1 | |
|
8.2
7.5
9 |
136
125
150 |
6
10
4 |
1450 |
2.6
4.0
1.9 |
3
5.5
2.2 |
5 |
B3.B5.V1 | ||||
|
50× 4A |
17.5
16 |
291
266 |
16
25 |
2900 |
11.6
16.5 |
15
18.5 |
4.5 |
80 |
50 |
B3 | |
|
8.2
7.5 |
136
125 |
16
25 |
1450 |
5.8
8.2 |
7.5
11 |
5 |
B3 | ||||
|
70×2 |
24
23
25 |
400
383
415 |
6
10
4 |
1450 |
7
9.8
5 |
11
15
5.5 |
4.5 |
100 |
65 |
B3.B5.V1 | |
|
15
14 |
250
233 |
6
10 |
970 |
4.8
6.5 |
5.5
7.5 |
5 |
B3.B5.V1 | ||||
|
70×4 |
24
22 |
400
366 |
16
25 |
1450 |
14
20.5 |
18.5
22 |
4.5 |
100 |
65 |
B3 | |
|
15
14 |
250
233 |
16
25 |
970 |
7.5
13.5 |
11
18.5 |
5 |
B3 | ||||
|
85×2 |
43
40
44 |
716
666
730 |
6
10
4 |
1450 |
12.2
18
9.5 |
15
22
11 |
4.5 |
125 |
80 |
B3.B5.V1 | |
|
28
25
30 |
466
416
500 |
6
10
4 |
970 |
8.5
10
6.7 |
11
15
7.5 |
5 |
B3.B5.V1 | ||||
|
85×4 |
43
40 |
716
666 |
16
25 |
1450 |
25
36 |
30
45 |
4.5 |
125 |
80 |
B3 | |
|
28
25 |
466
416 |
16
25 |
970 |
19.5
25.4 |
22
30 |
5 |
B3 | ||||
|
100×2 |
70
68
72 |
1166
1133
1198 |
6
10
4 |
1450 |
20
27.7
16 |
22
30
18.5 |
4.5 |
150 |
100 |
B3.B5.V1 | |
|
45
43
47 |
750
716
780 |
6
10
4 |
970 |
13.8
18.2
9.6 |
15
22
11 |
5 |
B3.B5.V1 | ||||
|
110×2 |
94
90
96 |
1566
1500
1560 |
6
10
4 |
1450 |
23
34
17 |
30
45
22 |
4.5 |
200 |
150 |
B3.B5.V1 | |
|
60
56
63 |
1000
933
1050 |
6
10
4 |
970 |
17.3
27.7
12.8 |
18.5
30
15 |
5 |
B3.B5.V1 | ||||
|
110×4 |
94
90 |
1566
1500 |
16
15 |
1450 |
53
80 |
75
90 |
4.5 |
200 |
150 |
B3 | |
|
60
56 |
1000
933 |
16
25 |
970 |
36
48 |
45
55 |
5 |
B3 | ||||
|
3GS
3GCS
3GSr
3GCSr
3GCL
3GCLS |
100×2 |
146
140
132
150 |
2433
2333
2200
2495 |
6
10
16
4 |
1450 |
35
50
80
30 |
45
55
90
37 |
4 |
250 |
150 |
B3.B5.V1 |
|
90
86
80
94 |
1500
1433
1333
1565 |
6
10
16
4 |
970 |
26
32.5
43
22 |
30
37
45
30 | ||||||
